SiC MOSFET Modules

All	Datasheet	PART NO.	Picture	Product Status	BVDSS (V)	RDS (on) (mΩ)Typ	RDS (on) (mΩ) Max	ID (A) @25°C	ID (A) @100°C	Configuration	VGS (V)	VGS(th) (V) Typ	Package	CAD模型	電路圖
		DACMI100N065BZK2		New	650	10	-	170	100	Single	-4/+18	2.9	SOT-227
		DACMI200N065BZK2		New	650	5	-	340	200	Single	-4/+18	2.9	SOT-227
		DACMI300N065BZK2		New	650	3.5	-	500	300	Single	-4/+18	2.9	SOT-227
		DACMI400N065BZK2		New	650	2.5	-	600	400	Single	-4/+18	2.9	SOT-227
		DACMI050N075BZK3		New	750	26	-	80	50	Single	-4/+15	2.4	SOT-227
		DACMI100N075BZK3		New	750	14	-	160	100	Single	-4/+15	2.4	SOT-227
		DACMI150N075BZK3		New	750	9	-	240	150	Single	-4/+15	2.4	SOT-227
		DACMI200N075BZK3		New	750	6.5	-	320	200	Single	-4/+15	2.4	SOT-227
		DACMI300N120BZK3		New	1200	5	-	450	300	Single	-4/+15	3	SOT-227
		DACMI050N120BZK3		New	1200	37	-	67	50	Single	-4/+15	3	SOT-227
		DACMI090N120BZK3		New	1200	18	-	125	90	Single	-4/+15	3	SOT-227
		DACMI100N120BZK3		New	1200	14.5	-	150	100	Single	-4/+15	3	SOT-227
		DACMI180N120BZK3		New	1200	10	-	250	180	Single	-4/+15	3	SOT-227
		DACMI200N120BZK3		New	1200	7.5	-	300	200	Single	-4/+15	3	SOT-227
		DACMI360N120BZK3		New	1200	4.5	-	500	360	Single	-4/+15	3	SOT-227
		DACMI400N120BZK3		New	1200	3.7	-	600	400	Single	-4/+15	3	SOT-227
		DACMI050N120BZK2		New	1200	35	-	67	50	Single	-4/+18	3	SOT-227
		DACMI090N120BZK2		New	1200	17	-	125	90	Single	-4/+18	3	SOT-227
		DACMI100N120BZK2		New	1200	18	-	135	100	Single	-4/+18	3	SOT-227
		DACMI120N120BZK2		New	1200	12	-	172	120	Single	-4/+18	3.3	SOT-227
		DACMI150N120BZK2		New	1200	12	-	200	150	Single	-4/+18	3	SOT-227
		DACMI200N120BZK2		New	1200	9	-	255	200	Single	-4/+18	3	SOT-227
		DACMI250N120BZK2		New	1200	6	-	370	250	Single	-4/+18	3	SOT-227
		DACMI350N120BZK2		New	1200	5	-	500	350	Single	-4/+18	3	SOT-227
		DACMI360N120BZK2		New	1200	4	-	500	360	Single	-4/+18	3.3	SOT-227
		DACMI480N120BZK2		New	1200	3	-	680	480	Single	-4/+18	3.3	SOT-227
		DACMI060N170BZK2		New	1700	26	-	90	60	Single	-4/+18	3.1	SOT-227
		DACMI120N170BZK2		New	1700	14	-	180	120	Single	-4/+18	3.1	SOT-227
		DACMI180N170BZK2		New	1700	9	-	270	180	Single	-4/+18	3.1	SOT-227
		DACMI240N170BZK2		New	1700	7	-	360	240	Single	-4/+18	3.1	SOT-227
		DACMI060N200BZK2		New	2000	32	-	85	60	Single	-4/+18	3.4	SOT-227
		DACMI063N200BZK2		New	2000	28	-	90	63	Single	-4/+18	3.1	SOT-227
		DACMI120N200BZK2		New	2000	16	-	170	120	Single	-4/+18	3.4	SOT-227
		DACMI125N200BZK2		New	2000	14	-	180	125	Single	-4/+18	3.1	SOT-227
		DACMI180N200BZK2		New	2000	11	-	250	180	Single	-4/+18	3.4	SOT-227
		DACMI190N200BZK2		New	2000	10	-	270	190	Single	-4/+18	3.1	SOT-227
		DACMI240N200BZK2		New	2000	8	-	340	240	Single	-4/+18	3.4	SOT-227
		DACMI250N200BZK2		New	2000	7	-	360	250	Single	-4/+18	3.1	SOT-227
		DACMA100N065BH2		New	650	10	-	170	100	Half-Bridge	-4/+18	2.9	SOT-227H-6
		DACMA200N065BH2		New	650	5	-	340	200	Half-Bridge	-4/+18	2.9	SOT-227H-6
		DACMA300N065BH2		New	650	3.5	-	500	300	Half-Bridge	-4/+18	2.9	SOT-227H-6
		DACMA050N075BH3		New	750	26	-	80	50	Half-Bridge	-4/+15	2.4	SOT-227H-6
		DACMA100N075BH3		New	750	14	-	160	100	Half-Bridge	-4/+15	2.4	SOT-227H-6
		DACMA150N075BH3		New	750	9	-	240	150	Half-Bridge	-4/+15	2.4	SOT-227H-6
		DACMA050N120BH3		New	1200	37	-	67	50	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA090N120BH3		New	1200	18	-	125	90	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA100N120BH3		New	1200	14	-	150	100	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA150N120BH3		New	1200	13	-	200	150	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA180N120BH3		New	1200	10	-	250	180	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA200N120BH3		New	1200	7.5	-	300	200	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA250N120BH3		New	1200	6.5	-	370	250	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMI300N120BZK3		New	1200	5	-	450	300	Half-Bridge	-4/+15	3	SOT-227H-6
		DACMA050N120BH2		New	1200	35	-	67	50	Half-Bridge	-4/+18	3	SOT-227H-6
		DACMA090N120BH2		New	1200	17	-	125	90	Half-Bridge	-4/+18	3	SOT-227H-6
		DACMA100N120BH2		New	1200	18	-	135	100	Half-Bridge	-4/+18	3	SOT-227H-6
		DACMA120N120BH2		New	1200	12	-	172	120	Half-Bridge	-4/+18	3.3	SOT-227H-6
		DACMA150N120BH2		New	1200	12	-	200	150	Half-Bridge	-4/+18	3	SOT-227H-6
		DACMA180N120BH2		New	1200	9	-	250	180	Half-Bridge	-4/+18	3	SOT-227H-6
		DACMA240N120BH2		New	1200	6	-	350	240	Half-Bridge	-4/+18	3.3	SOT-227H-6
		DACMA250N120BH2		New	1200	6	-	370	250	Half-Bridge	-4/+18	3	SOT-227H-6
		DACMA360N120BH2		New	1200	4	-	500	360	Half-Bridge	-4/+18	3.3	SOT-227H-6
		DACMA060N170BH2		New	1700	26	-	90	60	Half-Bridge	-4/+18	3.1	SOT-227H-6
		DACMA120N170BH2		New	1700	14	-	180	120	Half-Bridge	-4/+18	3.1	SOT-227H-6
		DACMA180N170BH2		New	1700	9	-	270	180	Half-Bridge	-4/+18	3.1	SOT-227H-6
		DACMA060N200BH2		New	2000	32	-	85	60	Half-Bridge	-4/+18	3.4	SOT-227H-6
		DACMA063N200BH2		New	2000	28	-	90	63	Half-Bridge	-4/+18	3.1	SOT-227H-6
		DACMA120N200BH2		New	2000	16	-	170	120	Half-Bridge	-4/+18	3.4	SOT-227H-6
		DACMA125N200BH2		New	2000	14	-	180	125	Half-Bridge	-4/+18	3.1	SOT-227H-6
		DACMA180N200BH2		New	2000	11	-	250	180	Half-Bridge	-4/+18	3.4	SOT-227H-6
		DACMA190N200BH2		New	2000	10	-	270	190	Half-Bridge	-4/+18	3.1	SOT-227H-6
		DACMA100N065B42		New	650	10	-	170	100	Four Switch	-4/+18	2.9	SOT-227H-8
		DACMA200N065B42		New	650	5	-	340	200	Four Switch	-4/+18	2.9	SOT-227H-8
		DACMA050N075B43		New	750	26	-	80	50	Four Switch	-4/+15	2.4	SOT-227H-8
		DACMA100N075B43		New	750	14	-	160	100	Four Switch	-4/+15	2.4	SOT-227H-8
		DACMA050N120B43		New	1200	37	-	67	50	Four Switch	-4/+15	3	SOT-227H-8
		DACMA090N120B43		New	1200	18	-	125	90	Four Switch	-4/+15	3	SOT-227H-8
		DACMA100N120B43		New	1200	14	-	150	100	Four Switch	-4/+15	3	SOT-227H-8
		DACMA180N120B43		New	1200	10	-	250	180	Four Switch	-4/+15	3	SOT-227H-8
		DACMA200N120B43		New	1200	7.5	-	300	200	Four Switch	-4/+15	3	SOT-227H-8
		DACMA050N120B42		New	1200	35	-	67	50	Four Switch	-4/+18	3	SOT-227H-8
		DACMA090N120B42		New	1200	17	-	125	90	Four Switch	-4/+18	3	SOT-227H-8
		DACMA100N120B42		New	1200	18	-	135	100	Four Switch	-4/+18	3	SOT-227H-8
		DACMA120N120B42		New	1200	12	-	172	120	Four Switch	-4/+18	3.3	SOT-227H-8
		DACMA180N120B42		New	1200	9	-	250	180	Four Switch	-4/+18	3	SOT-227H-8
		DACMA240N120B42		New	1200	6	-	350	240	Four Switch	-4/+18	3.3	SOT-227H-8
		DACMA060N170B42		New	1700	26	-	90	60	Four Switch	-4/+18	3.1	SOT-227H-8
		DACMA120N170B42		New	1700	14	-	180	120	Four Switch	-4/+18	3.1	SOT-227H-8
		DACMA060N200B42		New	2000	32	-	85	60	Four Switch	-4/+18	3.4	SOT-227H-8
		DACMA063N200B42		New	2000	28	-	90	63	Four Switch	-4/+18	3.1	SOT-227H-8
		DACMA120N200B42		New	2000	16	-	170	120	Four Switch	-4/+18	3.4	SOT-227H-8
		DACMA125N200B42		New	2000	14	-	180	125	Four Switch	-4/+18	3.1	SOT-227H-8
		DACMH100N065BH2		New	650	10	-	170	100	Half-Bridge	-4/+18	2.9	HB-9434
		DACMH200N065BH2		New	650	5	-	340	200	Half-Bridge	-4/+18	2.9	HB-9434
		DACMH300N065BH2		New	650	3.5	-	500	300	Half-Bridge	-4/+18	2.9	HB-9434
		DACMH400N065BH2		New	650	2.5	-	600	400	Half-Bridge	-4/+18	2.9	HB-9434
		DACMH050N075BH3		New	750	26	-	80	50	Half-Bridge	-4/+15	2.4	HB-9434
		DACMH100N075BH3		New	750	14	-	160	100	Half-Bridge	-4/+15	2.4	HB-9434
		DACMH150N075BH3		New	750	9	-	240	150	Half-Bridge	-4/+15	2.4	HB-9434
		DACMH200N075BH3		New	750	6.5	-	320	200	Half-Bridge	-4/+15	2.4	HB-9434
		DACMH050N120BH3		New	1200	37	-	67	50	Half-Bridge	-4/+15	3	HB-9434
		DACMH090N120BH3		New	1200	18	-	125	90	Half-Bridge	-4/+15	3	HB-9434
		DACMH100N120BH3		New	1200	14.5	-	150	100	Half-Bridge	-4/+15	3	HB-9434
		DACMH150N120BH3		New	1200	13	-	200	150	Half-Bridge	-4/+15	3	HB-9434
		DACMH180N120BH3		New	1200	10	-	250	180	Half-Bridge	-4/+15	3	HB-9434
		DACMH200N120BH3		New	1200	7.5	-	300	200	Half-Bridge	-4/+15	3	HB-9434
		DACMH250N120BH3		New	1200	6.5	-	370	250	Half-Bridge	-4/+15	3	HB-9434
		DACMH300N120BH3		New	1200	5	-	450	300	Half-Bridge	-4/+15	3	HB-9434
		DACMH360N120BH3		New	1200	4.5	-	500	360	Half-Bridge	-4/+15	3	HB-9434
		DACMH400N120BH3		New	1200	3.7	-	600	400	Half-Bridge	-4/+15	3	HB-9434
		DACMH050N120BH2		New	1200	35	-	67	50	Half-Bridge	-4/+18	3	HB-9434
		DACMH090N120BH2		New	1200	17	-	125	90	Half-Bridge	-4/+18	3	HB-9434
		DACMH100N120BH2		New	1200	18	-	135	100	Half-Bridge	-4/+18	3	HB-9434
		DACMH120N120BH2		New	1200	12	-	172	120	Half-Bridge	-4/+18	3.3	HB-9434
		DACMH150N120BH2		New	1200	12	-	200	150	Half-Bridge	-4/+18	3	HB-9434
		DACMH180N120BH2		New	1200	9	-	250	180	Half-Bridge	-4/+18	3	HB-9434
		DACMH200N120BH2		New	1200	9	-	255	200	Half-Bridge	-4/+18	3	HB-9434
		DACMH240N120BH2		New	1200	6	-	350	240	Half-Bridge	-4/+18	3.3	HB-9434
		DACMH250N120BH2		New	1200	6	-	370	250	Half-Bridge	-4/+18	3	HB-9434
		DACMH350N120BH2		New	1200	5	-	500	350	Half-Bridge	-4/+18	3	HB-9434
		DACMH360N120BH2		New	1200	4	-	500	360	Half-Bridge	-4/+18	3.3	HB-9434
		DACMH480N120BH2		New	1200	3	-	680	480	Half-Bridge	-4/+18	3.3	HB-9434
		DACMH060N170BH2		New	1700	26	-	90	60	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH120N170BH2		New	1700	14	-	180	120	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH180N170BH2		New	1700	9	-	270	180	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH240N170BH2		New	1700	7	-	360	240	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH060N200BH2		New	2000	32	-	85	60	Half-Bridge	-4/+18	3.4	HB-9434
		DACMH063N200BH2		New	2000	28	-	90	63	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH120N200BH2		New	2000	16	-	170	120	Half-Bridge	-4/+18	3.4	HB-9434
		DACMH125N200BH2		New	2000	14	-	180	125	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH180N200BH2		New	2000	11	-	250	180	Half-Bridge	-4/+18	3.4	HB-9434
		DACMH190N200BH2		New	2000	10	-	270	190	Half-Bridge	-4/+18	3.1	HB-9434
		DACMH240N200BH2		New	2000	8	-	340	240	Half-Bridge	-4/+18	3.4	HB-9434
		DACMH250N200BH2		New	2000	7	-	360	250	Half-Bridge	-4/+18	3.1	HB-9434
		DACMI060N120BZK		Active	1200	40	50	60	45	Single	-5/+20	2.7	SOT-227
		DACMI120N120BZK		Active	1200	20	25	120	90	Single	20	2.5	SOT-227
		DACMI180N120BZK2		Active	1200	16	18	180	135	Single	18	2.5	SOT-227
		DACMI240N120BZK2		Active	1200	10	11	240	180	Single	18	2.5	SOT-227
		DACMI060N170BZK		Active	1700	45	70	60	40	Single	20	3.4	SOT-227
		DACMI150N120BZK3		Active	1200	14	18	150	100	Single	15	2.5	SOT-227
		DACMI250N120BZK3		Active	1200	13	14	250	180	Single	15	2.5	SOT-227
		DACMI450N120BZK3		Active	1200	5	7	450	330	Single	15	2.5	SOT-227
		DACMH40N1200		Active	1200	60	80	40	25	Half-Bridge	20	2.4	HB-9434
		DACMH80N1200		Active	1200	28	34	80	50	Half-Bridge	20	2.5	HB-9434
		DACMH120N1200		Active	1200	20	25	120	76	Half-Bridge	20	2.5	HB-9434
		DACMH160N1200		Active	1200	16	20	160	110	Half-Bridge	20	2.5	HB-9434
		DACMH200N1200		Active	1200	13	15	200	125	Half-Bridge	20	2.5	HB-9434
		DASMM450N120BH3		Active	1200	5.8	-	450	300	Half-Bridge	15	2.1	HBA-15262
