Datasheet | PART NO. | Picture | Product Status | VCES(V) | IC(A) 25°C | VF(V) | Configuration | Technology | Package | CAD Model | Configuration |
|
|
 |
DAHF100G065SA
|
 |
Active | 650 | 100 | 1.6 | Half Bridge | Field Stop | HD-9434 (34mm) |
 |
 |
|
|
|
DAHF150G065SA
|
 |
Active | 650 | 150 | 1.65 | Half Bridge | Field Stop | HD-9434 (34mm) |
|
 |
|
|
|
DAHF150G120SB
|
 |
Active | 1200 | 150 | 2 | Half Bridge | Field Stop | HDA-10662 (62mm) |
|
 |
|
|
|
DAHF200G120SB
|
 |
Active | 1200 | 200 | 2 | Half Bridge | Field Stop | HDA-10662 (62mm) |
|
 |
|
|
|
DAHF225G120SB
|
 |
Active | 1200 | 225 | 2 | Half Bridge | Field Stop | HDA-10662 (62mm) |
|
 |
|
|
|
DAHF300G120SB
|
 |
Active | 1200 | 300 | 1.9 | Half Bridge | Field Stop | HDA-10662 (62mm) |
|
 |
|
|
|
DAHF075G120SA
|
 |
Active | 1200 | 75 | 2 | Half Bridge | Field Stop | HD-9434 (34mm) |
|
 |
|
|
|
DAHF100G120SA
|
 |
Active | 1200 | 100 | 2 | Half Bridge | Field Stop | HD-9434 (34mm) |
|
 |
|
|
|
DAHF150G120SA
|
 |
Active | 1200 | 150 | 2 | Half Bridge | Field Stop | HD-9434 (34mm) |
|
 |
|
|
|
DAZF075G120SCA
|
 |
Active | 1200 | 75 | 2 | Single | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF075G120SC2
|
 |
Active | 1200 | 75 | 2 | Single | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF100G120SCA
|
 |
Active | 1200 | 100 | 1.8 | Single | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF150G120SCA
|
 |
Active | 1200 | 150 | 1.8 | Single | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF075G120XCA
|
 |
Active | 1200 | 75 | 1.9 | Single w/o FWD | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF100G120XCA
|
 |
Active | 1200 | 100 | 1.9 | Single w/o FWD | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF150G120XCA
|
 |
Active | 1200 | 150 | 1.9 | Single w/o FWD | Field Stop | SOT-227 |
|
 |
|
|
|
DAZF100G170XCA
|
 |
Active | 1700 | 100 | 2.5 | Single w/o FWD | Field Stop | SOT-227 |
|
 |
